The MCL_PetDoctor is a suite of diagnostic tests which run on the MCL65+ board which is a drop-in replacement for the 6502 CPU which can emulate a cycle accurate processor along with all all of the computer’s RAM and ROM.

The MCL_PetDoctor diagnostics perform exhaustive tests on a PET motherboard at the optimal location – right at the CPU socket. Generating bus cycles at here allows it to test, toggle, peek, poke, and evaluate most of the PET’s motherboard logic. For signals it cannot reach it can perform general signal toggling or perform targeted bus cycles to help the user isolate and root cause faults.

Results are reported over the Arduino/Teensy JTAG UART so the video system of the computer does not need to be operational. The simple Arduino IDE or any terminal emulator can be used. See the capture below of the MCL_PetDoctor running on a Commodore PET 4016.

MicroCore Labs
MCL65_PETDoctor
Commodore PET Board Tester
----------------------------------------------

Tests Menu
----------
1) Test DRAM
2) Test ROMs
3) Dump ROMs
4) Toggle all 6502 output signals
5) PEEK
6) POKE
7) 6502 Clock, Reset, and Interrupts
8) Video
9) PIA and VIA Registers

Scan for stuck bits in the RAM space..........No stuck bits.
Pattern #1: Address as data...
Pattern #2: All 0x00..........
Pattern #3: All 0xFF..........
Pattern #4: Walking 1's.......
Pattern #5: Walking 0's.......
Pattern #6: Random data.......


MicroCore Labs
MCL65_PETDoctor
Commodore PET Board Tester
----------------------------------------------

Tests Menu
----------
1) Test DRAM
2) Test ROMs
3) Dump ROMs
4) Toggle all 6502 output signals
5) PEEK
6) POKE
7) 6502 Clock, Reset, and Interrupts
8) Video
9) PIA and VIA Registers

Generating 16-bit Checksums for ROMs..........
0xB000 Checksum: 4168
0xC000 Checksum: 5960
0xD000 Checksum: a425
0xF000 Checksum: cf19


Scan for stuck bits in the ROM space..........No stuck bits.


MicroCore Labs
MCL65_PETDoctor
Commodore PET Board Tester
----------------------------------------------

Tests Menu
----------
1) Test DRAM
2) Test ROMs
3) Dump ROMs
4) Toggle all 6502 output signals
5) PEEK
6) POKE
7) 6502 Clock, Reset, and Interrupts
8) Video
9) PIA and VIA Registers

PEEK from address: 0x123  DATA=0x1d


MicroCore Labs
MCL65_PETDoctor
Commodore PET Board Tester
----------------------------------------------

Tests Menu
----------
1) Test DRAM
2) Test ROMs
3) Dump ROMs
4) Toggle all 6502 output signals
5) PEEK
6) POKE
7) 6502 Clock, Reset, and Interrupts
8) Video
9) PIA and VIA Registers

POKEing DATA=0x5a to Address: 0x123


MicroCore Labs
MCL65_PETDoctor
Commodore PET Board Tester
----------------------------------------------

Tests Menu
----------
1) Test DRAM
2) Test ROMs
3) Dump ROMs
4) Toggle all 6502 output signals
5) PEEK
6) POKE
7) 6502 Clock, Reset, and Interrupts
8) Video
9) PIA and VIA Registers

6502 receiving a CLK........YES
6502 RESET level ...........HIGH
6502 IRQ_n level............HIGH
6502 NMI_n level............HIGH


MicroCore Labs
MCL65_PETDoctor
Commodore PET Board Tester
----------------------------------------------

Tests Menu
----------
1) Test DRAM
2) Test ROMs
3) Dump ROMs
4) Toggle all 6502 output signals
5) PEEK
6) POKE
7) 6502 Clock, Reset, and Interrupts
8) Video
9) PIA and VIA Registers

Filling PET screen with random letters..........


MicroCore Labs
MCL65_PETDoctor
Commodore PET Board Tester
----------------------------------------------

Tests Menu
----------
1) Test DRAM
2) Test ROMs
3) Dump ROMs
4) Toggle all 6502 output signals
5) PEEK
6) POKE
7) 6502 Clock, Reset, and Interrupts
8) Video
9) PIA and VIA Registers

PIA-1 Control-A Register FAIL 2a
PIA-1 Control-B Register FAIL aa
PIA-1 Control-A Register FAIL 19
PIA-1 Control-B Register FAIL 19
VIA Port-B Control Register FAIL cf


MicroCore Labs
MCL65_PETDoctor
Commodore PET Board Tester
----------------------------------------------

Tests Menu
----------
1) Test DRAM
2) Test ROMs
3) Dump ROMs
4) Toggle all 6502 output signals
5) PEEK
6) POKE
7) 6502 Clock, Reset, and Interrupts
8) Video
9) PIA and VIA Registers

The MCL_PetDoctor tests are written in simple C code and compiled/downloaded using the Arduino IDE so additional and custom tests can easily be added.

The project is open source and located on GitHub:  Github – MCL65+ Design Files

I can offer an MCL_PetDoctor board as a loaner to help you diagnose your Commodore PET or any other computer which uses a 6502 microprocessor. Please contact me for details.

Commodore PET Diagnostic Tester – MCL_PetDoctor

World’s Fastest Commodore PET using the MCL65+ 6502 drop-in emulator

MicroCore Labs, , , , , , , ,

I recently acquired and restored a Commodore PET 4016, so I thought it might be fun to try replacing the CPU with an MCL65+ 6502 drop-in replacement board to see how it performs. I also was interested to see how much faster the PET can operate when running in some acceleration modes!

My PET 4016, which normally contains 16 KB of DRAM, was upgraded to 32 KB by a previous user. This motherboard had holes drilled in the second DRAM bank by Commodore to keep users from upgrading their 4016 machines to 32 KB in and to force them to buy a PET 4032. This user simple hand-soldered the drilled out connections and upgraded it anyway!

As soon as I installed the MCL65+ it was able to booting the PET and I was able to run a small BASIC program. It had no trouble replacing the 6502 in the computer.

This is the MCL65+ installed in the computer’s CPU socket – replacing the 6502.

The next step was to test a theory that I had – I wondered if a .PRG program file could be loaded and run directly from the PET’s memory without needing a disk drive. This turned out to be the case!

The first two bytes of a .PRG binary file contains the memory address to locate the program and the rest of the file is simple the stream of binary data for the program. I simple converted the .PRG files to a string of hex data, placed it in an array in the MCL65+ code, and loaded it when the user presses a key.

Once the program was loaded I just needed to type RUN in BASIC and the program started up!

Being able to replace the 6502 and run programs directly from the internal memory was interesting, but I though it would be even more amusing to try some acceleration modes of the MCL65+ to see how fast we can run a Commodore PET.

Here is a video demonstration of me running a few programs and diagnostics using a few acceleration modes:


The MCL65+ uses a Teensy 4.1 which contains 1 MB of memory so it can easily emulate all of the PET’s ROM and RAM. With just a few line of code it can emulate different PET ROM images and diagnostic ROMs, support different sizes of system memory, and can mirror these memories in a cycle accurate or accelerated manners.

The video shows the computer running three acceleration modes. Mode-1, Mode-2, and Mode-3.

Mode-1 is cycle accurate where the MCL65+ runs just like a stock 6502 and is cycle accurate for both reads and writes. Mode-2 is cycle accurate on writes but accelerated on reads. Mode-3 is accelerated on both reads and writes. The accelerated modes store all of the computer’s RAM and ROM inside of the MCL65+ internal memory and run it at the maximum speed of the Teensy which is 900 MHz and clock accuracy is not observed.

I believe this machine is now the World’s Fastest Commodore PET!

World’s Fastest Commodore PET using the MCL65+ 6502 drop-in emulator

8088 CPU Emulator for the IBM PCjr – MCL86jr+

MicroCore Labs, , , , , , , , , , , ,

I got the MCL86+ running on the IBM PCjr by adding 8088 minimum mode support plus a few modifications to the PCB.

Project on GitHub: https://github.com/MicroCoreLabs/Projects/tree/master/MCL86%2B

Cycle accurate mode appears to work fine so I next added some acceleration by removing clock counting and mirroring all 640 KB inside of the Teensy. According to MIPS.COM, this IBM PCjr is as fast as a 80386.

The only issue I am running into is the inability to write to the floppy drive. Reads work fine but writes are inconsistent. I’m fairly sure I know why…

Early in the development of the MCL86jr+ I found that the PCjr BIOS is very (overly) reliant on 8088 instruction and bus timing.

Here is what I found:

In the BIOS POST CRT Attachment Test the MCL86jr+ would fail with ERROR 0908 and halting. Once I compared the sequence on a logic analyzer with a genuine 8088 I could see that the MCL86+ was performing opcode prefetches at the end of opcodes while the real 8088 interspersed them throughout the opcode execution. This resulted in the MCL86jr+ opcode execution being “tighter” and ready to accept interrupts earlier than the genuine 8088 could.

Shortly after the OUT opcode at address 0xF0452 which enables the vertical retrace interrupt was executed, the MCL86jr+ would accept and process the interrupt which disabled the source even before the main loop at address 0xF0459 had started. This code is not well written and is dependent on specific bus timing and recognition of the interrupt.

Also, I am certain that interrupts were already enabled before address 0x0F458, so the STI opcode should not have been necessary. I wonder if they added it as an attempt to guarantee that interrupts would not be accepted until at least the end of the TEST opcode. (They knew that interrupts are not accepted at the end on the STI opcode). Seems like a sloppy solution.

My guess is that there is another timing-dependent piece of code somewhere in the floppy write routine which is not tolerant of big differences in the MCL86jr+’s approach to opcode and bus timing.

8088 CPU Emulator for the IBM PCjr – MCL86jr+

MCLV20_Max / MCL86+ as a debug tool

MicroCore Labs, , , , , , , , ,

I picked up a IBM 5150 motherboard from the Silicon Valley Electronics Flea Market a a few weekends ago which appeared to be in very good condition.

I powered it up with just the power supply, VGA card, and the speaker to see if it could POST, but unfortunately it could not. Well, I did hear the pulse from the speaker which, I believe, means at least some of the BIOS was running.

To help debug this I plugged in an MCL86+ board, or more precisely, the MCLV20_Max which shares the same hardware and got the same results as the 8088.

I then wrote a bit of simple C code to perform a series of reads and writes to the BIOS ROM and the DRAM: I read a few bytes at FFFF:0000 and did some read/writes tests of the first DRAM bank at 0000:0000.

The ROM data at FFFF:0000 looked ok – it began with 0xEA which is the long jump. But the data returned from the DRAM was 0xFF for all DRAM banks – I checked pages 00000, 10000, 20000, 30000.

This could be caused by a number of things. The first places I looked with an oscilloscope were the control and data pins of the bi-directional data buffer between the CPU and the DRAM, then I examined the RAS, CAS, and WR_n signal.

It turned out to be the WR_n signal stuck at low. Unfortunately this signal is shared with ALL 36 DRAM chips! Any of them could have been dragging this signal down or it could have been another logic chip in this path. The first step was to pull all 27 of the socketed DRAMs but the problem persisted.

The next step was to look at the logic chips that generate WR_n starting from the ones closest to the DRAMs and working my way back. I isolated the stuck net at the output of the LS04 (inverter) so I snipped the output signal and checked it with the oscilloscope to confirm I had the right chip —But unfortunately I didn’t!

The net was still low which meant there was a short in one of the soldered-on DRAM chips or a short on the PCB.

I used an ohmmeter to see where the lowest resistance was to ground. I checked each socketed DRAM and was able to find that the lowest resistance was at the Bank-1 Parity DRAM! I thought this was strange – especially since there was no IC in the socket.

I thought I had better look under the PCB – and sure enough there was a short from the Parity DRAM’s WR_n signal (Pin-3) to the ground of bypass cap C7! It was because the factory did not clip the leads to many of the IC’s on this side of the PCB so they were long enough to touch an adjacent chip when bent over.

I clipped off the long pins and that was it! My tests were then able to read and write DRAM successfully I reinstalled the rest of the DRAMs and was also able to confirm they were all working.

The MCLV20_Max/MCL86+ made this debug much easier because the IBM BIOS doesn’t give much indication of what is wrong in situations like this. I also am using a VGA card so the diagnostic ROMs will not work.

With the MCLV20_Max I was able to write, compile, load, and run simple C code tests in minutes. I was able to isolate the issue to the DRAMs very quickly.

The IBM BIOS stops accessing DRAM as soon as it sees a failure, so it stops toggling the WR_n signal very quickly. The only way to get it to toggle would have been to constantly power cycle the machine which is both slow and stressful for the motherboard.

With the MCLV20_Max I was to hard-loop my write/read tests exclusively on the DRAM which guaranteed that the RAS/CAS/WR signals were always toggling so I could measure each IC in the signal path.

Once the debug was done I loaded in the MCLV20_Max code from GitHub in which booting from the MicroSD was recently added.

A fun fearure is that I am able to pre-set the acceleration mode to maximum so that the MCLV20_Max boots with the full 640 KB of RAM and acceleration many times faster than a stock 8088

:)

Here it is:

MCLV20_Max / MCL86+ as a debug tool

XTMax – 8-bit Software-Defined ISA card using Teensy 4.1

MicroCore Labs, , , , , , , , ,

XTMax is a software-defined 8-bit ISA card which uses a Teesny 4.1 microcontroller board that provides the functionality of THREE vintage ISA cards. It can expand “conventional” motherboard RAM up to 640 KB, adds up to 16 MB of Expanded RAM, supports 320 KB of UMB RAM, and provides bootable hard-drive access using a MicroSD card. A small PCB is used to allow nearly all of the ISA bus signals to attach to the Teensy 4.1.

A similar project to this is the PicoMem which is also a software-defined ISA expansion card, however the Teensy 4.1 used on the XTMax is nearly 3X faster than the Raspberry Pi Pico so does not share some of its limitations.

The first feature of XTMax is that it can expand the motherboard’s conventional (motherboard) ram up to 640 KB without limitation and with zero wait states. XTMax also has no limitation on the ability to support DMA to and from the computer’s floppy or spinning hard disks as PicoMem does.

XTMax can currently support 16 MB of Expanded RAM and 320 KB of UMB using a updated drivers.

XTmax also allows a MicroSD card to be accessed as a hard drive which is similar to the functionality of an XT-IDE card. By default it will be the boot device if there is no hard drive present.

All design files are open souce and posted to GitHub:

https://github.com/MicroCoreLabs/Projects/tree/master/XTMax

Here is the PCB developed using KiCAD:

And here is the actual board with a Teensy 4.1 attached:

Here is XTMax installed in a very early IBM 5150 rev-A which has 64 KB installed on the motherboard.

It shows that 4 MB of Expanded RAM was added and that the MicroSD card is accessible as the C: drive. The older IBM PC’s did not display the total amount of conventional memory, but in this application below the memory is expanded to the maximum of 640 KB.

It is worth noting that the first BIOS version of the IBM PC did not support extension ROMs and therefore do not support hard disks, so XTMax is currently the only way to have a hard disk equivalent on these machines!

Here is the total memory on this early PC as reported by Norton Utilities:

Here is a screen capture of the XTMax providing 16 MB of Expanded RAM and loads the UMB driver plus configures a 15 MB RAMDISK!

I posted a video on YouTube of the XTMax in action:

XTMax – 8-bit Software-Defined ISA card using Teensy 4.1

MCL6809 – Drop-in Motorola 6809E Emulator

MicroCore Labs2 Comments

The MCL6809 is a Motorola MC6809E cycle-exact, drop-in emulator which uses a Teensy 4.1 and a small PCB. The simple C code runs both the 6809 emulation and controls the local bus interface to the motherboard. The small PCB translates between the Teensy and MC6809E pinouts and provides a few voltage level shifters due to the fact that the Teensy IO’s are 3.3V and the motherboard IO’s are 5V.

The 6809 emulator timing follows the Motorola datasheet, so the core should be cycle-exact. It also supports all of the undocumented opcodes including HCF – Halt and Catch Fire.

On a Tandy Color Computer 2 it can boot Extended BASIC and run a number of programs that I typed in. It can also run cartridges with the binaries being emulated inside of the Teensy. At some point I will try some disk images once I acquire a drive or an emulator.

Once these applications were tested at the normal clock speed it was time to try some acceleration modes! The first, and easiest,  step was to eliminate the original MC6809’s VMA/Dummy bus cycles between most opcodes. The performance increase appeared to be close to 100% faster which was quite usable and enjoyable for most applications. The native CPU runsquite slow at under 1 Mhz, so doubling its speed made the machine more pleasant to use.

The next step was to mirror a portion of the motherboard RAM/ROM inside of the Teensy and run it at its native clock speed of 800 Mhz. This resulted in a very amusing but practically unusable amount of acceleration of over 800% faster – definitely yielding the world’s fastest CoCo!

While I was developing the core I needed a test suite to exercose each of the 6809 opcodes, flags, and addressing modes of my core. As far I could tell none were available, so I ended up writing my own. Fortunately it seems to have been good enough to improve my core to its current state.  Hopefully it can help other6809  core developers as well.

The MCL6809 core, the test core, and all PCB design files have been uploaded to GitHub.

YouTube video demo is here: https://youtu.be/v15GEWrfFuQ

Here is the MCL6809 booting to Color Computer BASIC:

Here is a close-up of the MCL6809:

This is the 3-D view of the board in KiCad

And a few cartridge titles:

MCL6809 – Drop-in Motorola 6809E Emulator

HP 1607A UPDATE

MicroCore Labs

I got the HP 1607A, which was previously non-functional, up and running!

I opened up the machine today and poked around looking for faults in a power rail, but upon first look every rail seemed ok. The voltage rails +5v, +12v, and -12v all looked fine.

The next step was to understand why the Z-blanking signal which is output at the rear of the machine was missing… I spent the next fifteen minutes or so tracking backwards until I found the source of the problem which was a missing 100 khz clock. The issue was some issue in this circuit:

It turns out that 5Vf was missing. I tracked it back to an earlier schematic page and it appears to be sourced from an inductor.

I grabbed my soldering iron and swapped this guy out…

That was it!

The HP 1607A was back in business!

HP 1607A UPDATE

HP 1600A and 1607A Logic State Analyzer

MicroCore Labs

I picked up a vintage HP 1600A/1607A logic analyzer set over the weekend which was state of the art back in 1975. I thought I would see if I could at least get them running and functional and then maybe develop some interesting stunt!

I was surprised that the 1600A was able to power up and render anything onto the display considering the fifty year old caps could be totally dried out by now and kept the power supply from working… The buttons were a bit sticky but none appeared broken.

The HP 1607A, however, was not able to send a sync signal on the Z channel, so in this case I do think there is an issue with its power supply likely due to dry caps. I will debug this machine some other time…

Since the HP1600A is a logic analyzer, the logical next step to test it would be to develop a way to generate stimulus, so I decided to employ a Teensy 4.1 to provide 32 data signals and two clock outputs. I whipped up some code and had a nice pattern on the analyzer in no time. One thing I found interesting was that when this unit is used as stand-alone, the 16 channels are justified to the left…

This was fun for about two minutes, so I began to look for a way to make this analyzer do something more interesting…

This analyzer also has a “MAP” function which is basically an addressable X-Y mode that allows the user to write to any of the display’s 64×64 pixels. This is enabled with the MAP switch at the top right. but it was not operating consistently due to the stickiness, so I had to take the machine apart to use contact cleaner on all of the switches and dials that I could reach.

Here is the offending switch which I doused with contact cleaner:

Once the machine was reassembled, MAP mode worked fine, so I made a small program to write pixels in random locations all around the screen which was much more interesting than walking-bit number paterns!

The next step after that was to try sending images to the display.  The best way I know to do this is by using images stored in BMP format which, for B&W images has either a 0 ot 1 for each pixel in the image.

I used GIMP to resize and export the images to a BMP file and made a small C program to convert and send the 64×64 image to the format used by the logic analyzer’s MAP mode to display on the screen.

When seen in real life the image has a very pleasant shimmers. Im guessing it may be because I am sending screen refreshes faster than the machine expects or was designed to handle, but is any case it looks nice… 🙂

The next step will be to crack open and debug the HP 1607A, but that’s a project for another day!

Here are a few more pictures of the insides of the HP 1600A:

HP 1600A and 1607A Logic State Analyzer

IBM PCjr Color Display Fix

MicroCore Labs

I took my IBM PCjr and its display out of storage, powered it up, and encountered this:

It appeared to be missing some colors – mainly blue.

I took the display apart and removed a metal shield from the neck-board. When I powered up the display there was nothing displayed! It took me a few minutes to realize that I had ripped off a trace which was soldered to the metal shield. I should have been more careful, but it was an easy fix…

Thanks to a user on the VCF web-site I was able to isolate the fault to a short in one of the capacitors on the neck board. I snipped one of the capacitor’s legs and the colors immediately returned! I replaced the cap and put the display back together. A quick fix thanks for the VCF community!

Happy to be back up and running again! 

PS: yes… this is a fast PCjr  🙂

IBM PCjr Color Display Fix
